PerkinElmer Lambda 365 Assembly/Installation Instructions

09931295C
4
Compatible Lambda 465 Cell Holders to Magnetic Stirrer Assembly
Accessory Drawing
Single Cell Holder
(Upon request)
Water Jacketed
Single Cell Holder
(Upon request)
8 Cell Water Jacketed Cell
Changer
Water Jacketed Automatic
Referencing Stage
 Where, the cell holder will be modified to be connected with the magnetic stirrer only upon
request.

PerkinElmer Lambda 365 Specifications

General

Wavelength Range	190 - 1100 nm
Power Requirements	100-240 V AC, 50/60 Hz
Wavelength Accuracy	±0.3 nm
Wavelength Repeatability	±0.1 nm
Wavelength Reproducibility	±0.1 nm
Photometric Repeatability	±0.001 Abs
Baseline Flatness	±0.0005 Abs
Baseline Stability	<0.0003 Abs/hour (after warm-up)
Data Interval	0.1 - 5 nm
Light Source	Tungsten halogen lamp and deuterium lamp
Sample Compartment	Standard 10 mm cell holder
Detector	Silicon Photodiode
