Perkins 403C-11 - Small End Bush

4
Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 43
400 Series
Small end bush
To remove and to fit Operation 4-11
Calculate the clearance between the small end bush and the gudgeon pin. if the clearance is greater than the
service limit, renew the bush.
Engine Clearance mm (in) Service limit mm (in)
403C-11 0,010 - 0,025 (0.00040 - 0.00099) 0.08 (0.0031)
403C-15
404C-22
404C-22T
0,010 - 0,025 (0.00040 - 0.00099) 0,10 (0.0040)
H1061
