Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 55
400 Series
Camshaft retaining plate
To remove and to fit Operation 6-5
The camshaft retainer plate is fitted between the cylinder block and the camshaft gear. The camshaft retainer
plate is fastened by either two setscrews or a setscrew and an allen screw.
Note: If the camshaft assembly is replaced the fuel adjustment screw must not be altered from the original
setting. The maximum no load speed must be checked after assembly.
Engine Torque Nm (lbf ft) kgf m
All models Camshaft retainer plate setscrews 11 (8) 1,1
H1072
