Workshop Manual, TPD 1458E, issue 3 - Perkins Confidential: Green 77
10
400 Series
Lubrication system 10
Lubricating oil canister
To fit Operation 10-1
1 Lubricate the seal with clean engine oil before assembly.
2 Tighten by hand until the seal contacts the mounting face of the block.
3 Tighten the canister by a further ½ to ¾ of a turn by hand only.
Note: Do not overtighten oil filter.
4 The modine cooler (1) and fastener (2) are fitted only to the 404C-22T.
1
2
H1119
