(Table 102, contd)
Troubleshooting Test Steps Values Results
9. Check the Crankshaft Timing Ring and the Camshaft
Position Wheel
A. Inspect the crankshaft timing ring. Refer to Disassembly
and Assembly, “Crankshaft Timing Ring - Remove and Install”.
B. Inspect the camshaft position wheel. Refer to Disassembly
and Assembly, “Camshaft Gear - Remove and Install”.
Defects Result: Found fault with the crankshaft timing ring or the cam-
shaft position wheel
If necessary, replace the camshaft position wheel. Refer to Dis-
assembly and Assembly, “Camshaft Gear - Remove and
Install”.
If necessary, replace the crankshaft timing ring. Refer to Disas-
sembly and Assembly, “Crankshaft Timing Ring - Remove and
Install”.
Use the electronic service tool in order to clear all logged diag-
nostic codes and then verify that the repair has eliminated the
fault.
Result: No faults found.
Contact the Dealer Solution Network (DSN).
10. Check if a Replacement ECM Eliminates the Fault
A. Contact the DSN.
B. If the DSN recommends the use of a replacement ECM, in-
stall a replacement ECM. Refer to Troubleshooting, “Replac-
ing the ECM”.
C. Use the electronic service tool to recheck the system for ac-
tive diagnostic codes.
Diagnostic
codes
Result: There are no active diagnostic codes with the replace-
ment ECM.
Reconnect the suspect ECM. If the fault returns with the sus-
pect ECM, replace the ECM.
Use the electronic service tool in order to clear all logged diag-
nostic codes and then verify that the repair eliminates the fault.
Result: The diagnostic code is still present with the replace-
ment ECM.
Contact the DSN.
UENR0612 217
Circuit Tests
