Permobil F5 Corpus - Page 47

F5 Corpus Repairs - Seat
Figure 110. The position of the screws on the new
model of the parallel panel holder.
Figure 111. The screw’s position on the earlier model of
the parallel panel holder and the rotational panel
holder.
5. Loosen the screw(s).
Figure 112. The new parallel panel holder is attached
by two nuts into the UniTrack.
Figure 113. The earlier model of the parallel panel
holder and the rotational panel holder is attached by a
clamp.
6. Pull out the panel holder.
47
