M1
Joystick panel, R-net LED control panel
Maximum speed indicator
Speed
1 - 2 LEDs
shows low speed
3 - 4 LEDs
shows average speed
5 LEDs
shows maximum speed
Figure 100. Maximum speed indicator.
Indicates the maximum speed set for the wheelchair.
Driving profile
For special applications, the wheelchair can be programmed with
more than one driving profile. In this case, the indicator LEDs will
instead display the selected driving profile. There can be up to 5
driving profiles.
NOTICE
Speed indicator also used as a fault indicator
The maximum speed or driving profile indicator also functions as a fault
indicator for the wheelchair’s electronics. See page 289 for further
information.
136
