Settings and adjustments
Figure 51. Adjusting armrest pad position.
Armrest pad position is adjustable for optimal comfort.
1. Loosen the four screws (A) under the armrest.
2. Slide the armrest pad to the required position.
3. Tighten the screws (A) using a torque wrench. Tightening
torque: 7.23 lb.ft.
Leg rest
WARNING!
Risk of injury while working on the leg rest
Do not place any weight on the legrest while working on it.
90
