Permobil Joystick Module for R-net
Charger socket
Figure 103. Charger socket.
This socket may only be used for charging or locking the
wheelchair. Do not connect any type of programming cable to this
socket. Do not use the socket as a power supply for any other
electrical device. Connection other electrical devices may damage
the control system or affect the wheelchair’s EMC (electromagnetic
compatibility) performance.
NOTICE
Use only the supplied battery charger
The wheelchair’s warranty will be voided if any device other than the
battery charger supplied with the wheelchair or the lock key is connected
via the control panel charger socket.
Buttons and paddle switches
On the control panel there is a total of 5 buttons and 2 paddle
switches.
142
