From the Panel Info page, the following panel parameters may be selected for display:
• IP Address – IP address assigned through Cattrax configuration to the Smart 32 panel
• Netmask – Subnet mask parameter for the Ethernet network
• Gateway – Gateway parameter for the Ethernet network
• MAC Address – MAC address of the SMART 32 panel
• Name – Panel name assigned through configuration to the Smart 32 panel
• ID – Hardware ID of the Smart 32 panel as set on the three rear panel rotary switches
• Serial # - Serial Number of the panel
• App Rev – Revision number of the main application software currently in the panel
• FPGA Rev – Revision number of the FPGA firmware code currently in the panel
• Controller IP – IP address of the system controller device communicating with the panel
• Controller Name – Identifying name assigned to the system controller
• Controller Status – Connection status of the panel to the system controller
• EXIT – Returns the Smart 32 panel to the previous key assignment page
The following control keys for adjusting display and pushbutton illumination (refer to Paragraph 4.14)
are also available through the Panel Info page:
• Backlight – Allows four steps of backlight intensity adjustment for the panel pushbutton keys
• Contrast – Allows display device character contrast adjustment over a relative range of 0 to 16
• Intensity – Allows display device backlight intensity adjustment over a relative range of 0 to 16
• UP Arrow – Increases adjustment value for the selected function
• DOWN Arrow – Decreases adjustment value for the selected function
4.5 S MART 32 P ANEL - K EY F UNCTIONS
With Smart 32 panels any pushbutton key on any page may be assigned to one router resource or
function, and is given a key type designation to identify its function. Each panel key is also color-coded
by type to quickly identify the various key functions on a key page. Key types and factory default
backlight colors are shown by Table 4-1. Backlight colors may be changed by key function on a system-
wide basis through menus in Cattrax. Individual panels may NOT select backlight colors on a single
panel basis.
