Cab, Instruments and Controls
58
Cooling
1. Switch the air conditioning on.
2. Switch the recirculation to position 1, 2 or 3.
3. Turn the temperature control switch to the desired position. For maximum
cooling set the knob to the far left position in the blue area.
4. Open the side and center vents.
While heating, it is possible to use the air conditioning to remove moisture from the
air in the cab. This has the advantage that demisting of the window glass will be
quicker.
Dehumidification
1. Switch the air conditioning on.
2. Turn the Fan Speed Switch to the Fresh Air setting.
3. Open the vents on the center console and side windows and set them as
desired.
4. Control the temperature as desired.
5. Adjust the volume of air using the fan speed selector switch.
NOTE
The air conditioning system is switched off when the engine coolant
temperature becomes too high. This will protect the engine.
