Inspections and Maintenance
93
ENGINE OIL LEVEL
1. Ensure that the vehicle is standing on a flat and level surface.
2. Open the front panel.
3. Pull the dipstick (2) out of the holder.
4. Wipe the dipstick clean with a lint-free cloth.
5. Re-place the dipstick in its holder. Withdraw the dipstick again and check the oil
level.
NOTE
It takes approx. 20 minutes for all the oil to run into the sump when the
engine is "warm". If the dipstick is checked immediately after switching
the engine off or immediately after oil has been added, the level shown
on the dipstick will be too low.
6. Fill oil through the filler opening (1) until the oil level reaches the maximum mark.
Only use engine oil that meets specifications. See "TECHNICAL DATA".
NOTE
For the difference between the minimum and maximum engine oil level,
see "TECHNICAL DATA".
