Cab, Instruments and Controls
64
7. ASHTRAY
In the center console there is an ashtray with auxiliary connection for the driver and
co-driver.
Do not connect any accessories above 180 Watt or any combination of accessories
that would require a combined amount greater than 180 Watts.
To remove the ashtray, there are two springs on the top of the tray which should be
pressed in, after which the tray can be removed.
8. HAZARD WARNING LIGHTS
When this switch is pressed, all the direction indicator lights flash simultaneously.
The hazard warning lights are switched off by depressing the switch again. The
warning light in the switch indicates that the hazard warning is switched on.
9. (unused)
11. (unused)
13. (unused)
15. PTO OPERATION
With this switch, the Power Take Off can be engaged, if necessary in combination
with the variable speed engine control. Engage the PTO only when the programmed
engaging conditions are met.
