Key Definitions
Handheld Remote:
Transmits the signal to the
Receiver Collar.
Tone Button (Green):
Sends an audible tone to
the collar. No Vibration
Stimulation is delivered.
Vibration Button
(Blue): Delivers Vibration
Stimulation through the
Vibration Points on the
Receiver Collar at the level
shown on the Digital Display.
A safety time-out will be
triggered if the button is held for more than 10 consecutive seconds. The safety time-out will end when the
button is released.
+2 Boost Button (Red): Adds a boost 2 levels above the currently selected Vibration Level. Can not
exceed the 8 High Level.
Vibration Down Button (-): Decreases Vibration Level by 1.
Vibration Up Button (+): Increases Vibration Level by 1.
Digital Display: Indicates Vibration Level, pairing mode and battery status. See “Prepare the
Handheld Remote” section for more details.
LED (Handheld Remote): 3 colours indicate which function the Handheld Remote is currently
performing.
Green LED: Indicates Tone Stimulation is being transmitted.
Red LED: Indicates Vibration Stimulation is being transmitted. Also indicates low battery.
Orange LED: Indicates pairing command is being transmitted.
LED
Tone Button
(green)
Digital Display
Vibration
Button (blue)
Vibration
Up
Button
+2 Boost
Button
Vibration
Down
Button
Belt Clip
Battery
Cover
Wrist
Strap
Loop
