TRAVERSE LIFT
Pettibone Michigan, L.L.C. OWNER/OPERATOR MANUAL MODELS 6036/6044/8036/8044
The axle identification plate is located on the backside of the axle, to the right of the differential. The
plate contains the axle part number, serial number and build date. The front axle is mounted with its
backside toward the front of the forklift. (See Figure 5.)
EQUIPMENT DESCRIPTION
FORKLIFT DESCRIPTION
The Extendo is a low profile, rough-terrain forklift with an approximate gross vehicle weight of 24,000
pounds (depending on the options used) and a lifting capacity of 6,000 to 8000 pounds. The Extendo is
equipped with four-wheel drive and a steering system that is capable of two-wheel steering, four-wheel
steering and oblique (crab) steering as selected by the operator.
STANDARD ENGINE DESCRIPTION
The Extendo is equipped with a Cummins Model 4BT3.9-CPL engine. This engine is a liquid-cooled,
four cylinder, four stroke, diesel engine with a displacement of 239 cubic inches (3.9L). The engine is
fuel injected and turbocharged with a rated output of 110 horsepower at 2500 rpm. The compression
ratio is 17.5:1.
TRANSMISSION DESCRIPTION
The transmission has three forward speeds and three reverse speeds. The transmission is equipped with
a mechanical disc-type parking brake, located on the output shaft to the forward drive axle.
AXLE DESCRIPTION
The forklift is equipped with two steerable drive axles. Both axles are equipped with internal, wet-type
disc brakes, located inside the planetaries, and a parking brake in both axles.
OPTIONS
Your Pettibone dealer offers a wide assortment of options for the Extendo forklift, including a variety of
forks, carriages, buckets and more. Contact your dealer for additional information and prices.PRE-
OPERATIONAL CHECKS AND SERVICES
