Pettibone Michigan, L.L.C. OWNER/OPERATOR MANUAL MODEL 6036/6044/8036/8044
TABLE VII. LUBRICATION POINTS
ITEM # GREASE POINT LOCATION(S)
1 Lift cylinder, shaft end (2)
2 Lift cylinder, base end (2)
3 Boom pivot pin (2)
4 Hydraulic system return line filter (1)
5 Wheel nuts, four locations
6 Tilt cylinder bushings (2), one on each end of cylinder
7 Machine boom side wear pads (2)*
8 Middle boom spacer blocks (2)
9 Front chain sheave (1)
10 Large boom spacer blocks (2)
11 Large boom side wear pads (2)*
12 Extend cylinder wear pad (1)*
13 Lube line for small boom top wear pads (2)*
14 Large boom bottom wear pad (1)*
15 Middle boom bottom wear pad (1)*
16 Fork frame pivot pin (2)
17 Middle boom rear top wear pads (2)*
18 Rear chain sheave (2)
19 Middle boom rear side wear pads (2)*
20 Small boom rear side wear pads (2)*
21 Small boom rear bottom wear pad (1)*
22 Middle boom rear bottom wear pad (1)*
23 Front drive shaft (3)
24 Rear drive shaft (3)
25 Steering knuckle (8)
26 Axle trunnion mounts (4)
27 Rear stabilization cylinder bushings (2) one on each end of cylinder
28 Sway cylinder bushings (2), one on each end of cylinder
* NOTE: No lube required on Nylatron wear pads
