Petzl RIG User Manual

TECHNICAL NOTICE RIG 1 D215000H (051216)
4
Rope access EN12841:2006 TypeC
8
Working load
limit:150kg.
The RIG descender
(certified to
EN12841:2006) is a
typeC rope adjuster
used to descend the
work rope. The RIG is a
braking device for rope
that allows the user to
manually control the
speed of descent and to
stop anywhere on the
rope by releasing the
handle.
To meet the requirements
of the EN12841:2006
typeC standard, use
10.5-11.5mm EN1891
typeA semi-static ropes
(core+ sheath).
Note:Certification testing
was performed at 150kg
using Petzl 10.5 to
11.5mm ropes.
8A. Descent
One person
Device attached to the
harness (handle in
positionC). You control
the descent by varying
your grip on the braking
side of the rope. To
descend, pull gradually
on the handle (positionD)
with one hand, holding
the braking side of the
rope with the other hand.
Release the handle to
stop the descent. When
the handle is released, it
returns automatically to
position(C).
Always hold the braking
side of the rope.
150 kg
MAXIMUM
2 m/s
maxi
150 kg
MAXIMUM
8
Rope access EN12841:2006 TypeC
9
Maximum descent height:200m
Normal working load:30-150kg
Lowering from an anchor-point
Device on the anchor:the braking side
of the rope must be redirected through a
carabiner. Hold the braking side of the rope
and move the handle up (positionD) to
allow the rope to slide. Braking is regulated
by varying the grip on the braking side of
the rope. Release the handle to stop the
descent. Lock the device on the rope by
moving the handle to positionB. Do not
force the handle to positionA, as this can
damage the device.
Information regarding standard
EN341
- Always tie a knot at the end of the rope.
- Equipment left in place must be protected
from the weather.
- Do not lose control during the
descent:descend at a reasonable speed.
- Warning, the device can overheat and
damage the rope during descent.
Rescue evacuation EN341 classA(1997)
2 m/s
maxi
150 kg MAXIMUM
10
Rescue plan
You must have a rescue plan and the means to rapidly
implement it in case of difficulties encountered while using
this equipment.
Anchors
The anchor point for the system should preferably be located
above the user’s position and should meet the requirements of
the EN795 standard (minimum strength of 10kN).
Various
- When using multiple pieces of equipment together, a dangerous
situation can result if the safety function of one piece of
equipment is compromised by the operation of another piece of
equipment.
- WARNING DANGER, take care that your products do not rub
against abrasive or sharp surfaces.
- Users must be medically fit for activities at height.
- The instructions for use for each item of equipment used in
conjunction with this product must be respected.
- The instructions for use must be provided to users of this
equipment in the language of the country in which the product
is to be used.
Supplementary information
regarding standards (EN365)
A
8B. Work positioning- secured stop
After stopping at the desired location, to go into work
positioning mode with hands free, lock the device on
the rope by moving the handle in the direction opposite
to that used for descent (turned to positionB) without
using excessive force. Once the handle has stopped at
positionb (positioning), do not force the handle. The
handle must not be in positiona (transport) with a rope in
the device. There is a risk of damaging the device that can
negate the braking function.
To unlock the system, firmly grip the braking side of the
rope and move the handle into descent position(D) to
descend.
Information regarding standard EN12841
ATTENTION, the RIG descender must be used with a
typeA backup device on a second (safety) rope (for
example, the Petzl ASAP fall arrester).
The RIG descender is not suitable for use in an EN363
fall arrest system.
Attach your descender directly to the harness using an
EN362 locking carabiner. Any equipment used with your
descender must be in compliance with current standards.
Do not allow the safety line to be loaded when the
working line is under tension.
A shock-load can damage the belay line.

Petzl RIG Specifications

General

Type	Descender
Material	Aluminum, steel, nylon
Maximum Working Load	200 kg
Certification	CE, EAC
Color	Yellow
