Mounting and commissioning the machine
8 - 5
8.03 Start inhibitor
8.03.01 Mounting the start inhibitor
● Set the machine into the table top.
● After loosening screws 2, set switch 1 so
that it is activated when the sewing head
is in an upright position.
● In this position tighten screws 2.
8.03.02 Checking the start inhibitor function
● Switch the machine on at the main switch and tilt back the sewing head.
The error message "E9" must appear on the control panel.
● If the message does not appear, check the setting of safety switch 1.
● Set the sewing head upright and acknowledge the error message by pressing the TE/
Speed
key. The machine is ready for operation again.
E9
ERROR
Fig. 8 - 07
1
2
