Pfaff 1171 User Manual

Mounting and commissioning the machine
8 - 6
8.04 Basic setting of the machine drive unit
● Switch on the machine.
● Press TE/Speed key twice to call up the input mode.
2 x
● By pressing the corresponding +/- key, call up parameter "798" and select service
level "C", see Chapter 10.05.01 Selecting the user level
TE
101 on
A
● By pressing the corresponding +/- key select parameter "700".
TE
798 11
C
TE
700
B
● Sew one stitch by operating the pedal.
● Turn the balance wheel in the direction of sewing until the tip of the needle is level with
the top edge of the needle plate.
● Conclude the adjustment of the sewing motor by pressing the TE/Speed key.
● By pressing the corresponding +/- key, call up parameter "800" (rotation direction of the
motor).
● By pressing the corresponding +/- key enter the value "0".
TE
800 0
C
