Adjustment
13 - 21
13
.05.19 Limiting the stitch length
The maximum stitch length which can be selected can be limited mechanically.
When using Version A and B part sets, the maximum adjustable stitch length
must not be larger than 3.0 or 4.5 mm (see chapter 3 Specifications)!
● Set the desired maximum stitch length with regulator disk 1.
● Move crank 2 (screws 3) down against stop 4.
2
4
3
Fig. 13 - 20
1
