Pfaff 1181

Adjustment
13 - 5
13.
05.03 Bottom feed neutral position
Requirement
At stitch length setting "0", cranks 1 and 3 must be flush and the feed dog must not make
any feeding motion when the balance wheel is turned.
● Raise the presser foot and set the stitch length to "0".
● Turn crank 1 (screw 2) according to the requirement.
Fig. 13 - 04
3
1
2
