Pfaff 1181

Adjustment
13 - 43
13
.11.03 Liste der Parameter
Gruppe
Parameter
Einstell- bereich
Einstell- wert
Nutzer- ebene
Bedeutung
1 101 Control panel beep tone A, B, C on
6 605 Speed display B, C off
607 Speed max. B, C 300 - 6000 4000
609 Cutting speed B, C 60 - 500 180
660 Bobbin thread control A,B,C 0 - 2 0
0 = off
1 = thread monitor
2 = reverse counter
7 700 Needle postion 0
(needle reference position) B,C 0 – 255
702 Needle position 1 (needle lowered) B,C 0 – 255 90
703 Needle position 2 (take-up lever raised) B, C 0 - 255 236
705 Needle position 5 (end of cutting signal 1) B, C 0 - 255 200
706 Needle position 6 (start of cutting signal 2) B, C 0 - 255 136
707 Needle position 9 (start thread tension
release) B,C 0 - 255 164
797 Hardwaretest B, C off
798 User level A,B,C 0,1,11 0
0 = User level
1 = Technician level
11 = Service level
799 Selected machine class C 1 - 3 1
8 800 Rotating direction of the motor C 0 - 1 0
Further parameters are listed in the Motor Instruction Manual.
