Adjustment
9
Fig. 13 - 04
13
.04.04
Needle height
(pre-calibrating)
Rule
When the needle bar is in b.d.c., the clearance between the needle bar and needle plate
should be
15 mm
.
O
Adjust the needle bar
1
( screw
2
) without twisting according to the
rule
.
1
2
15 mm
8
10
