Preparations
Changing the needle
Switch off the main switch
To remove: Lower the presser foot and set the needle to its
highest position. Loosen the needle screw (52) and pull the
needle out downwards.
To insert: The fl at side A of the
needle must face to the rear.
Lower the presser foot and insert
the needle, pushing it up as far
as it will go. Hold the needle and
tighten the needle screw (52)
fi rmly.
Threading the twin needle:
Replace the sewing needle with a twin needle. Insert the second
spool pin and place one spool of thread on each of the spool
pins. During threading in the left threading slot (34), make
sure that you pass one thread each to the left and right sides
of tension disk B. Continue threading in the usual manner,
making sure the threads do not become twisted together. Pull
the threads right and left into the thread guide and thread the
needles.
Note: It is not possible to use the integrated needle threader with a
twin needle.
