Pfaff SMART 300E - Cleaning

42
User’s Guide
Cleaning
Turn off power and
unplug from electrical
outlet.
1. Loosen the screws on
the needle plate and
remove.
2. Lift out the bobbin case.
3. Clean the area with a
small soft brush.
4. Replace the bobbin
case so that the hook
tab rests against the
stop.
Clean the bobbin
area on a regular
basis, and more
frequently when
embroidering on
fabric with nap such
as fl eece or terry.
Hook Tab
Stop Spring
