Pfaff SMART 300E - Overview

4
User’s Guide
Overview
Familiarize yourself with the names of
the parts of your machine. This will help
you in learning its operation.
1. Bobbin winder
2. Handwheel
3. Main power switch
and connectors
4. USB connection
5. Control Panel
6. Embroidery hoop
holder
7. Needle plate
8. Bobbin cover
9. Presser foot
10. Needle threader
11. Start/Stop button
12. Presser foot lever
13. Bobbin winding
guide
14. Upper thread
tension
15. Spool cap
16. Spool felt
