Operating Manual | Roof-mounted Cooling Unit | Multi Controller (MC) – 230 V | 086100023d 12/80
3.4 Functional description
3.4.1 Air circuit
CAUTION
Risk of burns
Risk of burns due to high temperatures at the ambient air outlet. The air outlet can get very hot depending on the ambient
temperature.
• Do not hold any parts of the body directly in front of the ambient air outlet (A).
Front view View from below
Fig. 1: Air circuit switch cabinet DTT
A Ambient air outlet
B Ambient air inlet
C Hot air inlet (switch cabinet)
D Cold air outlet (switch cabinet)
1 DTT-cooling unit
G00027
