Operating Manual | Roof-mounted Cooling Unit | Multi Controller (MC) – 230 V | 086100023d 13/80
3.4.2 Filter adapter (option)
Fig. 2: Filter adapter on the cooling unit
For permanent protection of the external air circuit from contamination, the optional filter adapter (1) can be fitted with a filter
mat (2) at the air inlet (3) of the cooling unit.
The filter adapter (1) is simply clipped into the air inlet (3). Only one filter adapter per unit is needed. All filter types are suitable
for the adapter.
Order number Description
18310000151 Filter adapter, RAL 7035
18300000147 Felt filter (standard, dusty air without oil vapors)
18300000148 Pleated filter (longer life, dusty air without oil vapors)
18300000149 Aluminum filter (oily air)
Tab. 1: Order information filter adapters and filter mats
