Operating Manual | Roof-mounted Cooling Unit | Multi Controller (MC) – 230 V | 086100023d 27/80
3.7 Technical data
3.7.1 Refrigeration circuit
Designation Model DTT 6101 Model DTT 6201
Cooling capacity at A35 / A35 */* Q
0
50 Hz 500 W 1000 W
Q
0
60 Hz 665 W 1100 W
Cooling capacity at A50 / A35 */* Q
0
50 Hz 370 W 600 W
Q
0
60 Hz 400 W 640 W
Refrigerant type * R134A
Refrigerant quantity * 400 g
Temperature setpoint (factory setting) +35 °C (+95 °F)
Fault indication: Switch cabinet interior
temperature
(factory setting)
SC-Controller: > +50 °C (+122 °F)
MC-Controller: > +52 °C (+125.6 °F)
Ambient air temperature +15 °C (+59 °F) to +55 °C (+131 °F)
Switch cabinet interior temperature +25 °C (+77 °F) to +45 °C (+113 °F)
Air volume flow, exterior circuit 1820 m³/h
Air volume flow, interior circuit 570 m³/h
Condensate separation Condensate evaporator
Sound pressure level (1 m) ≤ 62 dB(A)
Tab. 6: Refrigeration data
* Data on the type plate.
NOTE
The use of optional filter mats reduces the cooling capacity
3.7.2 Electrical data
Designation Model DTT 6101 Model DTT 6201
Rated voltage * *** 230 V, 1~
Rated frequency * 50/60 Hz
Functional area DIN IEC 60038
Power consumption * A35 / A35 P
el
50 Hz 458 W 663 W
P
el
60 Hz 532 W 805 W
Condensate evaporator power consumption P
el
30 to 110 W (A35/A35 approx. 70 W)
Nominal current * I
nom max
50 Hz 2.36 A 3.98 A
I
nom max
60 Hz 3.00 A 4.50 A
Start-up current * I
Start max
50 Hz 19.7 A 14.8 A
I
Start max
60 Hz 23.0 A 17.4 A
* Data on the type plate.
*** Adapt the upstream fuse if the rated voltage changes, see "Adapting the unit to the mains voltage", Page 50.
