Pfannenberg DTX 8161 - Page 37

685408006D 39
Model
DTI/DTS 8161 IC
Cooling capacity at A35/A35 * **
Q 0
1000/1100 W
Cooling capacity at A50/A35 * **
Q 0
860/920 W
Refrigerant type/ Refrigerant amount *
R 134a/320 g
Thermostat setting, (factory set)
+35°C (+95°F)
failure indication: Enclosure internal temp. (factory set)
> +50°C (+122°F)
Enclosure internal temp.
+25°C (+77°F) . . . +45°C (+113°F)
Air volume, external/ internal circulation °)
1200m³/h/570 m³/h
Condensation discharge
Condensate discharge pipe.(Option: condensate evaporator )
Noise level (1m)
 68 dB(A)
Electrical data
Rated voltage&Mains frequency
230 V&50/60 Hz
Operating range
DIN IEC 60038
Power consumption *
P el
A35/A35: 565/598 W (without option)
Option: Condensate evaporator(CM)
P el
30-110W (A35/A35 ca. 70W)
DTI/DTS 8161 IC HS
DTI/DTS 8161 IC LAP
Current capacity *
I nom max
4,2/4,7 A
9,2/10,1 A
Starting current *
I Start max
17,5 A
28,0 A
Heatting capacity
-
1000W
Ambient air temperature
+15°C (+59°F) . +55°C (+131°F)
-40°C (-40°F).+55°C (+131°F)
Dimensions
Height X Width X Depth (standardwith front cover on) °°)
976 X 450 X312 mm
Installation depth DTI °°)
ca.64 mm
Weight(with front cover on)
DTI/DTS 8161
DTI/DTS 8161 LAP
40.7kg
41.4kg
Installation attitude
vertical
Unit construction
Standard: steel Option: Stainless
Corrosion protection
Standard:galvanized, electrostatically powder coated (200°C)
Option:Stainless, Aluminium
Protection system according to EN 60529
IP54 against the enclosure, under correct operating conditions.
IP34 against the environment, under correct operatingconditions.
