Appendix
Shown parameters (operation display):
Hierarchy 
Parameter
Hierarchy 
Parameter
Description
Min.
Max.
Default
Unit
Temperature
-tp-
Pb1
Cabinet air inlet tempeture Read only
-40
60
-

Pb2
Cabinet air outlet tempetureRead only
-40
60
-

Pb3
Ambient air inlet tempetureRead only
-40
60
-

Pb4
Ambient air outlet Read only
-40
60
-

t1 *
Internal control setting
25
45
35

t2 °)
Energy saving tempeture setting
15
25
25

t5 °)
Heating start temperature
0
10
5

t6 °)
Heating stop temperature
5
15
10

t8 °)
Cabinet air outlet tempeture setting
0
10
5

Humidity
-Hr-
rh
Current humidityRead only
0
99
-
%
rh1 °)
Dehumidification hysteresis
60
75
60
%
rh2 °)
Humidity setting
80
99
85
%
Communication
(-Co-)
Add *
Address
1
255
1
baU *
Baud rate
0
5
3
Alarm
-AL-
no6
Device fault signalRead only
0
1
-
no7
Power fault signalRead only
0
1
-
Power
-Po-
U
Voltage input Read only
0
1000
-
V
SC
Current input Read only
0
1000
-
A
Time
(-tt-)
year
year
1990
9999
-
onth
onth
1
12
-
date
date
1
31
-
hour
hour
0
24
-
Fnut
Fnut
0
59
-
Scnd
Scnd
0
59
-
Discrete
output
(-dg-)
d1
Reservation not enabled
0
1
-
d2
Reservation not enabled
0
1
-
d3
High-pressure switch Read only
0
1
-
d4
Door switch Read only
0
1
-
no1
Internal fanRead only
0
1
-
no2
External fanRead only
0
1
-
no3
Reservation not enabled
0
1
-
no4
HeaterRead only
0
1
-
no5
Compressor Read only
0
1
-
Simulation
parameter
-Ag-
r1
Tempeture currentRead only
4
20
-
A
r2
Humidity currentRead only
4
20
-
A
Enable
-En-
Eco °)
Energy saving
0
1
0
Historical
alarm
-hS-
Exxx
Alarm code
1
200
E001
