Pfeiffer Vacuum PASCAL Series - Exploded Views and Parts List

N – 2
1
57
58
59
55
54
53
49
48
47
46
45
43
43
43a
43b
43a
59a
43c
42
41
41a
40
39
38
37
36
35
34
33
44
52
2
3
4
4a
5
6
7
8
11
12
13
14
15
16
17
17a
23
18
19
20
8a
21
22
28
26
9
10
C
M
B
or
D
or
A
1015I
1015I
Plan de montage cuve et bâti
Oil casing and central housing assembly drawing
Ölbehälter und Pumpenträger Gesamtplan
Rep. Part
Clamping torque
(N·m)
2 Screw FHC M5 x 10 4.0
9 Screw CHC M6 x 25 9.5
14 / 20 Screw FHC M6 x 12 12.5
28 Screw M5 x 16 (s.steel) 7.0
38 Screw CHC M6 x 12 9.5
45 Screw CHC M6 x 25 9.5
52 / 57 Screw CHC M4 x 10 2.0
