EN – 4
Tools and consumable products
Overhaul kit
Seal kit This kit contains all the seals on the pump which must be replaced at each complete
disassembly.
Pumps 1005 1015 2005 2010 2015 2021
I – 105515 103912
SD / SDI 103911 105515 103911
C1 104975
C2 – 104975
Keep this kit in a dry place, away from heat and light (sunlight and ultraviolet light),
in order to prevent any hardening of the elastomers (see AFNOR standards: “storage
conditions for vulcanized elastomer based products” - FD T.46 022).
Special precautions
Read the safety instructions at the beginning of the maintenance chapter.
Before disassembling the pump, drain it (see Operating instructions).
All the seals and faulty parts should be replaced: provide a seal kit or an
overhaul kit.
Spare parts
In addition to the seal kit, this kit contains a set of spare parts to perform overhaul on
the pump for a two year period, under normal operating conditions.
Pumps 1005 1015 2005 2010 2015 2021
I – 104643 103906 103907 103908 103909
SD / SDI * 104622 104643 103902 103903 103904 103905
C1 104617 104619 104976 104977 104978 104979
C2 – – 104614 104615 104616
* For SDI pump with no flanged stator, use a major kit P/N 108308.
The pumps are equipped with :
• a shouldered not chromed ring (36) for I, SD and SDI models with serial number
< AM656245
• a shouldered chromed ring (36) for I, SD and SDI models with serial number
≥ AM656245
• a shouldered chromed ring (36) for C1 and C2 models.
The shouldered not chromed ring is a spare part that must be replaced with a
chromed ring.
The shouldered chromed ring needn’t systematically to be changed.
For fasted service, specify the following when ordering:
- Pump type.
- Serial number (on pump label).
- Part number (see list at end of operating instructions).
Overhaul kits containing the most frequently used parts are always available at our sales
outlets. Be sure to use these kits so you will have all the parts necessary.
