What to do if Pfeiffer Vacuum Measuring Instruments show SENSOR ERROR I?
If the Pfeiffer Vacuum Measuring Instruments display a 'SENSOR ERROR I', it indicates an interruption or instability in the sensor line or connector. You can acknowledge the error using the key. If the problem persists, 'Sx noSENSOR' or 'Sx noIDENT' may be displayed.
Why do I get WATCHDOG ERROR I on my Pfeiffer Vacuum Measuring Instruments?
If the Pfeiffer Vacuum Measuring Instruments display a 'WATCHDOG ERROR I', it could be due to the device being turned on too quickly after being powered off, or due to a severe electrical disturbance or operating system error that tripped the watchdog. Acknowledge the error using the key. If the watchdog is set to Auto, the TPG 36x will automatically acknowledge the message after 2 seconds.
What to do if Pfeiffer Vacuum Measuring Instruments display PROGRAM CORRUPT I?
If the Pfeiffer Vacuum Measuring Instruments display a 'PROGRAM CORRUPT I' error, it indicates a program memory error (FLASH). Acknowledge the error using the key.
What does DATA CORRUPTED I mean on Pfeiffer Vacuum Measuring Instruments?
If the Pfeiffer Vacuum Measuring Instruments display a 'DATA CORRUPTED I' error, it means there is a parameter memory error (EEPROM). You can acknowledge it with the key.
What causes DISPLAY ERROR I on Pfeiffer Vacuum Measuring Instruments?
If the Pfeiffer Vacuum Measuring Instruments display a 'DISPLAY ERROR I', it indicates a display driver error. Acknowledge the error using the key.
What does A/D ERROR I mean for Pfeiffer Vacuum Measuring Instruments?
If the Pfeiffer Vacuum Measuring Instruments display an 'A/D ERROR I', it indicates an error with the A/D converter. Acknowledge the error using the key.
General| Temperature Range | 0 to 50 °C |
|---|---|
| Power Supply | 24 VDC ±10% |
| Communication | RS-232, RS-485 |
| Display | LCD |
| Power Consumption | 5 W |
| Protection Category | IP 40 |
| Operating Temperature | 0 to 50 °C |
| Storage Temperature | -20 to 70 °C |
| Measurement Range | 1E-9 to 1000 hPa |
| Output Signal | 0-10 V, 4-20 mA |
Explanation of symbols used for safety warnings and indicators.
Requirements for personnel performing operations described in the manual.
General safety precautions and guidelines for operating the equipment.
Specifications for measured pressure values, errors, and rates.
Parameters for controlling the activation and deactivation of gauges.
Technical details for various communication interfaces including protocols and rates.
Specifies the qualifications required for installation personnel.
General guidelines for installing and setting up the device.
Details on connecting the device to the main power supply, including safety.
Description of the TPG 36x front panel components and display elements.
Instructions for safely turning the TPG 36x device on and off.
Explanation of the various operating modes available on the TPG 36x.
Details on the standard operating mode for displaying measurements and statuses.
Description of how to access and edit device parameters organized into groups.
Configuration of switching functions, thresholds, and channel assignments.
Parameters for configuring connected gauges, including calibration and filtering.
Parameters for controlling the activation and deactivation of gauges.
Configuration of general device parameters and system settings.
Using the device as a data logger for measurement data storage.
Accessing setup options for saving, loading, and managing parameters.
Interpreting error signals and troubleshooting common error messages.
Procedures and information for updating the device firmware.
Step-by-step guide for updating firmware using a USB memory stick.
Instructions for updating firmware using the dedicated USB Update Tool software.
