Phanteks Eclipse P600s User Manual

16
HDD
4x
REQUIRES:
3.5” HDD INSTALLATION
4x Phanteks Stackable 3.5” HDD Brackets are included.
Additional brackets are sold separately (PH-HDDKT_03).
The HDD bracket can also house
a 2.5” SSD instead of a 3.5” HDD.
Each HDD bracket can be stacked together to oer more exibility.
HDD INSTALLATION STACK / INSTALL REMOVE
1. LIFT UP LATCH
2. PULL OUT
2
2
1
1
A
C
B
195mm PSU Clearance
250mm PSU Clearance
POSITION A+C
POSITION B
INSTALLING DRIVES
BOTTOM COMPARTMENT
The Bottom Compartment can house up to 2 or 4 Stackable HDD trays. Using Position B will not limit
PSU or Front radiator clearance.

Phanteks Eclipse P600s Specifications

General

Form Factor	Mid Tower
Dimensions	240 mm x 520 mm x 510 mm (W x H x D)
Material	Steel, Tempered Glass, Plastic
Radiator Support	Front: Up to 360mm, Top: Up to 360mm, Rear: Up to 140mm
Maximum GPU Length	435 mm
Maximum CPU Cooler Height	190 mm
Dust Filters	Front, Top, Bottom
Motherboard Support	ATX, Micro-ATX, Mini-ITX
Expansion Slots	7
Front I/O Ports	1x USB 3.1 Gen 2 Type C, 2x USB 3.0, Audio In/Out, Power Button, Reset Button
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Pre-installed Fans	Front: 2x 140mm, Rear: 1x 140mm
Weight	13.5 kg
