Phanteks Eclipse P600s User Manual

22
CONNECTING FRONT I/O
POWER BUTTON
2X USB 3.0
POWER LED
MICROPHONE
RESET BUTTON
Please make sure to consult your
motherboard manual before connecting
your front I/O.
Power LED
HD
AUDIO
TO MOTHERBOARD
USB 3.0
Please consult the motherboard manual for additional instructions.
Power SW
Reset SW
USB 3.1 GEN 2 TYPE-C
HEADPHONE

Phanteks Eclipse P600s Specifications

General

Form Factor	Mid Tower
Dimensions	240 mm x 520 mm x 510 mm (W x H x D)
Material	Steel, Tempered Glass, Plastic
Radiator Support	Front: Up to 360mm, Top: Up to 360mm, Rear: Up to 140mm
Maximum GPU Length	435 mm
Maximum CPU Cooler Height	190 mm
Dust Filters	Front, Top, Bottom
Motherboard Support	ATX, Micro-ATX, Mini-ITX
Expansion Slots	7
Front I/O Ports	1x USB 3.1 Gen 2 Type C, 2x USB 3.0, Audio In/Out, Power Button, Reset Button
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Pre-installed Fans	Front: 2x 140mm, Rear: 1x 140mm
Weight	13.5 kg
