16
SHIFT 2
SHIFT 2 air
INSTALLING THE GPU
Install the GPU on the GPU bracket rst before placing it in the chassis. The GPU bracket is congured to
face the GPU cooler towards the side panel out of the box. If you prefer to face the GPU cooler towards the
motherboard, please move the stand-o as shown in step 3.
PLACE THE GPU ONTO THE GPU BRACKET
1.
SECURE THE GPU WITH 2X SCREWS (PSU SCREWS)
2.
OPTIONAL: MOVE THE STAND-OFF IF YOU WANT TO FACE THE GPU
COOLER TOWARDS THE MOTHERBOARD. THE STAND-OFF CAN BE
EASILY LOOSENED AND REPOSITIONED WITH A FLAT SCREWDRIVER
3.
2
3
1
2x
REQUIRES:
