19
RESERVOIR INSTALLATION
OPTIONAL PUMP BRACKET
4x
The universal Pump Bracket can be installed in
the bottom compartment using 4 case screws.
Pump Bracket sold separately
(PH-PUMBKT_01)
26mm
Reservoir mounting points are accessed
by removing the Cable Covers.
1x
REMOVE:

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Phanteks Evolv X and is the answer not in the manual?

Phanteks Evolv X Specifications

General IconGeneral
Form FactorMid Tower
Motherboard SupportE-ATX, ATX, Micro-ATX, Mini-ITX
MaterialAluminum, Steel, Tempered Glass
Maximum GPU Length435 mm
Maximum CPU Cooler Height190 mm
Power SupplyATX
Maximum PSU Length250 mm
Front I/O Ports2 x USB 3.0
Cooling SupportFront: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Dimensions240 mm x 520 mm x 520 mm (W x H x D)
Included Fans3 x 140 mm (2 Front, 1 Rear)
Expansion Slots7+3
