Phanteks Evolv X User Manual

2
3. Support
Contact us 30
Warranty 31
1. What’s inside?
Introduction 3
Specications 4
Exploded view 5
Accessories 6
2. Choose your setup
Congure your Evolv X 7
Get started 8
Installing motherboard 10
Installing power supply 11
Installing fans
Connecting the Fan Hub
12
Installing drives 14
Installing water cooling
Radiator installation
Pump/Reservoir installation
17
Installing GPU Anti-Sag Bracket 20
TABLE OF CONTENTS
Connecting front I/O 21
D-RGB lighting
Sync lighting with D-RGB motherboard
22
Cable Management 24
Optional Upgrades: 25
Installing vertical GPU 27
Installing Dual System 28

Phanteks Evolv X Specifications

General

Form Factor	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Aluminum, Steel, Tempered Glass
Maximum GPU Length	435 mm
Maximum CPU Cooler Height	190 mm
Power Supply	ATX
Maximum PSU Length	250 mm
Front I/O Ports	2 x USB 3.0
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Dimensions	240 mm x 520 mm x 520 mm (W x H x D)
Included Fans	3 x 140 mm (2 Front, 1 Rear)
Expansion Slots	7+3
