Phanteks Evolv X User Manual

20
GPU ANTI-SAG BRACKET
To prevent your GPU from tipping down you can install the
GPU Anti-Sag Bracket.
REQUIRE:
2x
INSTALLING GPU ANTI-SAG BRACKET
1.
2.
INSTALL ALL GPU AND PCI CARDS
PLACE THE GPU ANTISAG BRACKET
3.
4.
INSERT THE THUMBSCREWS WITHOUT
TIGHTENING THEM
PRESS DOWN AND LOCK THE
THUMBSCREWS IN POSITION.
3
Always loosen the 2 thumb screws
before removing any GPU or PCI card.
2
4

Phanteks Evolv X Specifications

General

Form Factor	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Aluminum, Steel, Tempered Glass
Maximum GPU Length	435 mm
Maximum CPU Cooler Height	190 mm
Power Supply	ATX
Maximum PSU Length	250 mm
Front I/O Ports	2 x USB 3.0
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Dimensions	240 mm x 520 mm x 520 mm (W x H x D)
Included Fans	3 x 140 mm (2 Front, 1 Rear)
Expansion Slots	7+3
