Phanteks Evolv X User Manual

14
INSTALLING DRIVES
2.5” SSD INSTALLATION
Both SSD Covers support 3x 2.5” SSDs.
Each SSD is mounted with 4x screws.
REQUIRE:
4x
CABLES
4x
OPTIONAL SSD STORAGE
Up to 3x additional SSDs can be installed using
the *Phanteks 2,5” SSD bracket (PH-SDBKT_01).
*SSD brackets are not included and sold separately.
PH-SDBKT_01 required
4x
REMOVE:

Phanteks Evolv X Specifications

General

Form Factor	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Aluminum, Steel, Tempered Glass
Maximum GPU Length	435 mm
Maximum CPU Cooler Height	190 mm
Power Supply	ATX
Maximum PSU Length	250 mm
Front I/O Ports	2 x USB 3.0
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Dimensions	240 mm x 520 mm x 520 mm (W x H x D)
Included Fans	3 x 140 mm (2 Front, 1 Rear)
Expansion Slots	7+3
