Phanteks Evolv X User Manual

25
OPTIONAL UPGRADES
3.5” STACKABLE HDD BRACKETS PH-HDDKT_03
2.5” SSD BRACKET PH-SDBKT_01
CABLE EXTENSION SET PH-CBCMBO
- Available in multiple colors
- Includes clear cable combs
- Also available as separate cables
Included cables:
- Motherboard 24-pin
- CPU 4+4-pin
- 2x GPU 6+2-pin
PHANTEKS PH-F120MP / PH-F140MP
For 3.5” or 2.5” Drive
Upgrade up to 6x additional 3,5”
HDDs with the optional HDD
brackets.
For 2.5” SSD Drive
Upgrade up to 3x additional
2,5” SSDs with the optional SSD
brackets.
High static pressure 120/140 mm fans
More fans can be installed in the Evolv X
and connected to the Universal Fan Hub
using splitter cables.
PAGE 15
PAGE 14
PAGE 12
PAGE 22
PAGE 22
DIGITAL-RGB LED COMBO SET PH-DRGBLED_CMBO
HALOS (LUX) DIGITAL RGB FAN FRAMES
PH-FF120DRGBA PH-FF120DRGBP
PH-FF140DRGBA PH-FF140DRGBP
High density Digital-RGB LED strips
with magnets
The D-RGB equipped Evolv X is
ready to expand with more D-RGB
lighting products.
High density Digital-RGB LED fan
frames that illuminate any fan.
The D-RGB equipped Evolv X is
ready to expand with more D-RGB
lighting products.
Y-SPLITTER CABLES PH-CB-Y4P / PH-CB-Y3P
4-pin / 3-pin Fan splitters
More fans can be connected to the
Universal Fan Hub using splitter
cables.
PAGE 13

Phanteks Evolv X Specifications

General

Form Factor	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Aluminum, Steel, Tempered Glass
Maximum GPU Length	435 mm
Maximum CPU Cooler Height	190 mm
Power Supply	ATX
Maximum PSU Length	250 mm
Front I/O Ports	2 x USB 3.0
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Dimensions	240 mm x 520 mm x 520 mm (W x H x D)
Included Fans	3 x 140 mm (2 Front, 1 Rear)
Expansion Slots	7+3
