Phanteks Evolv X User Manual

26
220 mm Slimline PCI-E x16 Riser Cable 90° PH-CBRS_SL22
220 mm Premium Shielded High Speed PCI-E x16 Riser Cable 90° PH-CBRS_PR22
600 mm Premium Shielded High Speed PCI-E x16 Riser Cable 90° PH-CBRS_PR60
ITX Upgrade Kit PH-ITXKT_02
Vertical GPU installation
With the optional Riser Cable you can place any 2- or 3-slot GPU vertically.
Vertical GPU installation for 2nd system (Dual system conguration)
With the optional Riser Cable you can place any 2- or 3-slot GPU
vertically for your 2nd ITX system.
Dual System installation
With the optional Riser Cable you can
place any 2- or 3-slot GPU vertically for
your 2nd ITX system.
PAGE 27
PAGE 29
PAGE 28
Revolt X Power Supply PH-P1000PS
PH-P1200PS
Dual System installation
T he Revolt X power supply unlocks the
Dual System Conguration. But also works
great as a “single system” power supply.
PAGE 11

Phanteks Evolv X Specifications

General

Form Factor	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Aluminum, Steel, Tempered Glass
Maximum GPU Length	435 mm
Maximum CPU Cooler Height	190 mm
Power Supply	ATX
Maximum PSU Length	250 mm
Front I/O Ports	2 x USB 3.0
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Dimensions	240 mm x 520 mm x 520 mm (W x H x D)
Included Fans	3 x 140 mm (2 Front, 1 Rear)
Expansion Slots	7+3
