Phanteks Evolv X User Manual

4
INCLUDED ACCESSORIES
Premium fan 140 mm 3x (installed)
Universal Fan Hub 1x (installed)
3.5” stackable HDD bracket 4x
Vertical GPU Mount 1x
Accessory bag 1x
Anti-Sag Bracket 1x
Airow Cover 1x
Toolbox 1x
CLEARANCE
CPU Cooler Clearance 190 mm (7.48 in)
GPU Clearance 435 mm (17.24 in)
Front Radiator thickness 95 mm (3.74 in)
Top Radiator thickness 65 mm (2.56 in)
SUPPORT
Contact (International) support@phanteks.com
Contact support@phanteksusa.com
(North and South America)
Warranty 5 Years*
CASE SPECIFICATIONS
Dimension 240 mm x 520 mm x 510 mm
(WxHxD) 94.5 in x 20.5 in x 20.1 in
Form Factor Mid Tower
Materials Anodized aluminum panels
Powder coated steel chassis
Tempered glass side panels
MB Support E-ATX, ATX, Micro-ATX, Mini ITX
Front I/O Power button, 2x USB 3.0,
Microphone, Headphone, D-RGB
Mode button, D-RGB Color button,
USB 3.1 GEN 2 Type-C
Side Window Yes, Tempered glass both sides
PCI SLOTS & DRIVE BAYS
PCI slots 7x
Internal 3.5” 10x (4 included)
Internal 2.5” 9x (6 included)
FAN 120 mm 140 mm
Front 3x 3x (2 installed)
Top 3x 2x
Rear 1x 1x (1 installed)
RADIATOR 120 mm 140 mm
Front Up to 360 Up to 420
Top Up to 360 Up to 280
Rear 120 140
SPECIFICATIONS
*see page 31

Phanteks Evolv X Specifications

General

Form Factor	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Aluminum, Steel, Tempered Glass
Maximum GPU Length	435 mm
Maximum CPU Cooler Height	190 mm
Power Supply	ATX
Maximum PSU Length	250 mm
Front I/O Ports	2 x USB 3.0
Cooling Support	Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm
Dimensions	240 mm x 520 mm x 520 mm (W x H x D)
Included Fans	3 x 140 mm (2 Front, 1 Rear)
Expansion Slots	7+3
