v | P a g e
V2.1
WARNING: Input power connections should be made by a qualified electrician
into circuit with adequate voltage and current carrying capacity for the model. Branch
circuit protection to the unit should be provided by appropriately sized fuses or a 2-pole
circuit breaker.
CAUTION: Use 600 V vinyl-sheathed wire or equivalent. The voltage drop of the
leads needs to be considered in determining wire size. Voltage drop is dependent on
wire length and gauge. Use only copper conductors.
CAUTION: Wires fastened to the terminal blocks shall be secured by tightening
the terminal screws to a torque value listed in Table 14 - Table 17.
CAUTION: The input wire gauge must be sized for the single-phase input current,
which will be significantly larger than the three-phase output current to the load. The
minimum wire gauge for the input terminals is listed in Table 13.
CAUTION: Never allow bare wire to contact metal surfaces.
CAUTION: Never connect AC main power to the output terminals T1, T2, and T3.
WARNING: Under certain conditions, the motor load may automatically restart
after a trip has stopped it. Make sure power to the converter has been disconnected
before approaching or servicing the equipment. Otherwise, serious injury may occur.
