PAS 280 Operation Guide
2. System Overview
Page 15 of
46
Table 1. Dataflow for PAS 280 System with DSM 400 Stabilizer
Sequence
in Figure
12
Signal/Data
From
To
Protocol
Description
1
NMEA or
Applanix
GSOF
Applanix
POS AV
iX
Controller
NMEA or
GSOF
over
TCP/IP
Applanix POS AV sends NMEA data
required by iX Flight to calculate
aircraft position and flight director.
2
Camera
trigger
iX Flight
Camera
Analog
I/O
discrete
iX Flight (in iX Controller) calculates
when to take a picture (based on
NMEA/GSOF data received from
Applanix POS AV) and issues a
trigger.
3
MEP (Mid
Exposure
Pulse)
Camera
Applanix
POS AV
Discrete
Camera sends an event input to the
POS AV when the picture is taken.
4
Event data
Applanix
POS AV
Camera
RS-232
POS AV sends event metadata to
camera for image metadata.
A
(ongoing)
Start/Stop
pass
iX Flight
SOMAG
DSM 400
stabilizer
RS-232
• iX Flight (in iX Controller) sends
angle data to SOMAG DSM 400
stabilizer for stabilization.
• iX Flight (in iX Controller)
calculates Start of Line and before
reached, sends "Stab" command to
SOMAG DSM 400 stabilizer.
• iX Flight (in iX Controller)
calculates End of Line and after
reached, sends "Manual" command
to SOMAG DSM 400 stabilizer.
B
(ongoing)
GIM01
SOMAG
DSM 400
stabilizer
Applanix
POS AV
RS-232
SOMAG DSM 400 stabilizer platform
sends GIM01 message with platform
angles to the POS AV for registration
in T04 files.
C
(ongoing)
Images
Camera
iX
Controller
USB
Images taken by camera transferred
to iX Controller SSD.
D
(ongoing)
Internal
IX Flight
IX Capture
Internal
TCP/IP
iX Flight sends line number and image
in the line number to iX Capture for
tagging image filenames.
Figure 13 and Table 2 details the dataflow for a PAS 280 system with a GSM 4000 stabilizer.
