Phcbi MLR-352 - Cooling Unit Parts

- 6 -
Cooling unit parts

MLR-352/352(H)
                           
Components Specifications
Compressor 115V,60Hz * 220~240V,50Hz 220V,60Hz
Model RL2557-PB RL2557-SA RL2557-RA
Parts code
7FB-0-M101-008-02 7FB-0-M101-008-03 7FB-0-M101-008-04
Rated power supply 110/115V, 60Hz 220-240V, 50Hz 220V, 60Hz
Refrigerant oil SL32D1 Charged q’ty:290ml
Cooling method Air cooling by fan
Starting relay
P6R0SAT PGR0SAT PGR0SAT
Overload relay
5.6C36C1 2.8C36C1 3.2C36C1
Starting capacitor
120MF,160VAC 60MF,300VAC 60MF,300VAC
Running capacitor
20MF,260VAC 6MF,400VAC 6MF,400VAC
Condenser
Evaporating pipe
W240×P25×3.5columns㸦ij4.76×t0.7mm㸧
Condenser
Fin and tube
W180×P25×4linesx7.5columns㸦ij7.94×t0.6mm㸧
Frame pipe ij4.0×t0.5mm
Evaporator
Type
Fin and tube
W380×2lines×12columns
Accumulator ij35×L210mm
Evaporator for
de-humidity
Tube: W360×1line×4columns
Capillary tube
Place
Evaporator
Evaporator for
de-humidity *
By-passing
expansion valve
Resistance 57PSI
6kgf/
111PSI
Dimensions
L1500xOD2.4xID1.2 L1200xOD1.8 L2000xOD2.0xID0.9
Refrigerant Type R-404A
Charged q’ty 290g
Dryer Type XH-9
Charged q’ty 10g
Condensing fan
Condensing fan motor
Dimensions ij140, Fin:7pcs Material: Aluminum and resin
Type
Cooling fan
Cooling fan motor
Dimensions ij140, FIn:7pcs Material: Aluminum and resin
Type
Sensor Temp. sensor Type: 103AT-1
Defrost sensor Type: 103AT-1
Heater DEF heater 318W
Drain pan heater 20W
*It is applicable for MLR-352H type only.








