PM15-4A RECOMMENDED SPARE PARTS LIST
Qty.
Phenix
Stock #
Item
Description
1
1001839
PAPER ROLL *
PAPER ROLL FOR PANEL PRINTER MPP5510
1
1077170
PWR CORD
18/3 9’10” RT ANG MOD PWR CORD #37F3354
1
1422150
SW1 *
31-903.2 LENS, EAO RED
1
1422151
SW2 *
31-903.5 LENS, GREEN
2
1420145
SW1-2 *
10-1313.1249 EAO LAMP 28V
1
1590009
BATT. PACK
7 CELL BATTERY PACK
1
1077330
PS2
HV CABLE ASSY 15kVDC 18”
1
30070022
OUTPUT CABLE
HV OUTPUT CABLE ASSY (PM15-4A)
1
30080004
RTN CABLE
RETURN CABLE ASSY – 10 FT
1
30080005
GND CBL
GROUNDING CABLE ASSY – 10 FT
