2.4 IO Port
① ② ③ ④ ⑤ ⑥ ⑦ ⑧
① [Ear jack]
3.5mm Ear Jack(CTIA standard) with mic in
② [HDMI OUT]
HDMI video/audio output
③ [LED]
power on --> LED change to yellow after 5s --> LED change to Green when PHILIPS LOGO appear.
④+⑥ [Micro USB]
Support USB external device.
⑤ [Micro SD]
Connect your Micro SD card.
⑦ [LAN]
* LAN control function for the use of remote control signal from control center.
* PoE+(power over Ethernet): 24W
Status
Green
Yellow
NC
OFF
OFF
10Mbps
ON (Flicker)
OFF
100Mbps
ON (Flicker)
ON
⑧ [DC 12V]
Switch the AC adapter on/off
