Philips 10BDL3051T User Manual

10BDL3051T
35
MAIN, ADIF ,ATDS Header AAC-LC and
AAC-HE(AAC,M4A)
Dynamic content
W3C HTML5 (HTML, CSS, JavaScript)
W3C SMIL 3.0 instructions (sub-set)
Physical I/O connectors
3.5mm analog stereo audio out port
HDMI output port
RJ45 Ethernet port
Micro SD card slot(up to 32GB micro SDHC)
DC -in Jack for charging(12V 1.5A)
Micro USB for ADB *1
Micro USB for host*2
Type A host ports*2
reserved expansion port
Local storage
8 GB eMMC with Micro SD card expansion slot
Accessories
DC Power adapter
HDMI Cable
USB Cable
Stand Bar
Silicon Foot
Power plug(US/EU/UK)
Quick start guide
Power requirement
12V 1.5A DC
802.3af compliance PoE, power over Ethernet
Power consumption*
10.96 watts max
Environmental
Operating temperature: 0 – 40° C / 32 – 104° F
Storage Humidity: 10 – 85% @ 40° C / 104° F
non-condensing
Dimensions
261 x 167.2 x 29 mm
Weight
0.740kg
Safety
UL/CB certified AC adapters
Certifications
CE/FCC/IC/BQB/HDMI
Warranty
One-year limited parts & labor
6.2. Disclaimer
Image Retention Disclaimer
When an image is monitored on-screen for prolonged periods of time, you may see a faint image after it is
replaced. This is expected normal behavior for monitors.
Image retention may be reduced by:
* Avoiding still images shown on-screen for more than a few minutes
* Using non-contrasting colors and brightness
* Using background colors other than gray

Philips 10BDL3051T Specifications

General

Multi-touch	Yes
Aspect ratio	16:10
Response time	30 ms
Display diagonal	10.1 \
Display brightness	300 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Contrast ratio (typical)	800:1
Display number of colors	262144 colors
Display diagonal (metric)	25.6 cm
Number of simultaneous touchpoints	5
Built-in camera	No
Power supply type	DC
Placement supported	Horizontal/Vertical
USB 2.0 ports quantity	1
Mean time between failures (MTBF)	50000 h
Certification	CB, CE, FCC A, UL
Product color	Black
Glass thickness	0.7 mm
Panel mounting interface	75 x 75 mm
Number of OSD languages	18
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
RMS rated power	4 W
Number of built-in speakers	2
Cables included	DC, HDMI, USB
Sustainability certificates	RoHS
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (standby)	0.5 W
Power consumption (typical)	6 W
Compatible memory cards	MicroSD (TransFlash)

Weight and Dimensions

Depth	29 mm
Width	261 mm
Height	167.2 mm
Weight	710 g
